SPECIFICATIONS

Capacity: 1-20 ton

Design pressure: 1.0Mpa,1.25Mpa 1.6Mpa 2.5Mpa

Fuel: Biomass, coal, straw, wood

Life span: more than 30 years

Material: Q345R steel plate,Q345R Steel Plate

Product name: Automatic coal fired chain grate stoker steam boiler

Rated evaporation capacity: 0.5-35t/h

Steam temperature: 174-225 degree

Style: Horizontal

Thermal efficiency: more than 85%

Warranty: 2 Years

Weight (KG): 1000

brand name: HengNuo

core components: boiler body

dimension(l*w*h): Depends on boiler capacity

key selling points: Easy To Operate,Long Service Life,Automatic,Low Maintenance Cost

machinery test report: Provided

output: Steam

place of origin: Henan, China

pressure: Low Pressure

structure: fire and water tube

type: Natural Circulation

usage: Industrial

video outgoing-inspection: Provided

Welcome to contact me for more discounts

Product Introduction:

The SZL double drum longitudinal chain grate boiler adopts a double drum longitudinal arrangement, and the boiler burns biomass formed solid fuel. The water-cooled walls on both sides of the furnace adopt a membrane water-cooled wall structure; The water-cooled wall tubes on the front and rear walls of the furnace extend downwards to the upper part of the grate, forming front and rear arches. This not only increases the sealing performance of the boiler, but also increases the furnace volume and heating surface, while reinforcing the strength of the rear arch. The fuel falls from the coal hopper onto the grate and is burned after entering the furnace with the grate. The flue gas enters the convection tube bundle area and passes through the smoke wall. The flue gas flows towards an S-shaped bend and uses inertia to separate the dust in the flue gas, which then falls into the four gravity type automatic ash hoppers set below. It then moves with the grate and falls into the slag hopper, where it is discharged from the furnace body by the slag extractor.

Application scenarios：

This boiler is widely used in hospitals, schools, hotels, government agencies, pharmaceutical industry, food factories, beverage factories, rubber factories, greenhouses, chemical industry, paper mills, building materials industry, clothing and textile factories, washing plants, etc

Product Paramenters

Model Project

SZL2-1.25-T SZL2-1.6-T SZL2-2.5-T SZL1.4- 0.7/95/70-T Quick installation

SZL4-1.25-T SZL4-1.6-T SZL4-2.5-T SZL2.8- 0.7/95/70-T Quick installation

SZL6-1.25-T SZL6-1.6-T SZL6-2.5-T SZL4.2- 1.0/95/70-T Modular installation

SZL8-1.25-T SZL8-1.6-T SZL8-2.5-T SZL5.6- 1.0/95/70-T Modular installation

SZL10-1.25-T SZL10-1.6-T SZL10-2.5-T SZL7- 1.0/95/70-T Modular installation

Rated evaporation(mw)

2/1.4

4/2.8

6/4.2

8/5.6

10/7

Working pressure(MPa)

1.25/1.6/2.5/0.7

1.25/1.6/2.5/0.7

1.25/1.6/2.5/1.0

1.25/1.6/2.5/1.0

1.25/1.6/2.5/1.0

Rated steam temperature(℃) Outlet temperature(℃)

194/204/226/95

194/204/226/95

194/204/226/95

194/204/226/95

194/204/226/95

Water supply temperature(℃) Return water temperature(℃)

20/70

20/70

20/70

20/70

20/70

be heated area(m²)

Essence(m²)

70

100

142

215

234

Economizer(m²)

35

66

130

130

174

Effective area of grate(m²)

3.22

6.72

7.52

10.25

11.8

Fuel type

Biomass pellets,low calorific valueQ≈21000KJ/Kg

Boiler fuel consumption(kg/h)

~300

~590

~880

~1160

~1450

Exhaust gas temperature(℃)

135~145

Boiler thermaleficiency(%)

83~84

Maximum transport item weight(t)

5500×2350×3650

7730×2360×3520

upper 6150×2840×3540 below 7275×2852×2580

upper 6971×2933×3540 below 8056×2945×2580

upper 7855×3240×3540 below 9025×3200×2580

The parameters are changed due to technical innovation,and the factory parameters are subject to the actual drawings!

Our Advantages：

(1) High thermal efficiency The boiler adopts a convective arrangement, with high heat transfer efficiency on the heating surface. The efficiency characteristics of the boiler operation are stable and have a certain degree of overload operation capability (2) Reasonable water circulation system Reasonable water circulation system, large water capacity, ample steam space, and good steam quality; (3) Stable combustion The cross-sectional ratio between the descending surface and the ascending pipe of each heating surface is reasonable, and the combustion conditions are stable; (4) High furnace temperature Reasonable matching of front and rear arches, high coverage of furnace arches, high furnace temperature, and the ability to burn coal with combustible volatiles greater than 20% (5) Adjustable air volume Each air chamber can be manually adjusted according to the required air volume for each combustion stage of the fuel, and the lateral air pressure is consistent, so there will be no phenomenon of partial combustion (6) Good sealing performance Each air chamber is equipped with a pull-out cast iron ash discharge door at the bottom, which is not easily deformed, easy to use, and has good sealing performance
