SPECIFICATIONS

Brand Name: JECHIM

Bucket capacity: 0.11m³, 0.06-0.3

Core Components: PLC, Pressure Vessel, Other, Gear, Engine, Motor, Pump, Gearbox, Bearing

Engine Brand: top brand

Hydraulic Cylinder Brand: top brand

Hydraulic Pump Brand: top brand

Hydraulic Valve Brand: top brand

Machine Weight: 3980 kg

Machinery Test Report: Provided

Make: top brand

Max Digging Radius: 2416mm

Maximum Digging Depth: 3440mm

Maximum Digging Height: 5715mm

Moving Type: Crawler Excavator

Origin: Mainland China

Place of Origin: China

Power(W): 21.2kW

Rated Speed: 4.5

UNIQUE SELLING POINT: High load Moment

Video outgoing-inspection: Provided

Warranty: 1 Year

Welcome, my friend! If you need other models of this product, feel free to let me know and I'll send you the link. For quick assistance, The shipping fees on AliExpress may be inaccurate. Please message me before placing an order to get the correct fees. Let me know if you need anything! please contact me via WAp: +86 19173199094 or maoyishunda@gmail.com.

Personal Business Card

Product Parameters

Parameter	9035E
Operating Weight With Cab(kg)	3980
Operating Weight with Canopy(kg)	3860
Engine Capacity(kw/rpm)	21.2/2100
Bucket Capacity(m3)	0..6-0.3
Max. Travel Speed (High)(km/h)	4.6
Max. Travel Speed(Low)(km/h)	2.7
Max. Swing Speed(rpm)	10
Arm Breakout Force(kN)	20
Arm Breakout Force Power Boost(kN)	--
Bucket Breakout Force(kN)	30
Shipping Length(mm)	4810/4860
Shipping Width(mm)	1700
Shipping Height(mm)	2500
Track Shoe Width(std)(mm)	300
Boom(mm)	2450
Arm(mm)	1320/1700
Digging Reach(mm)	5385/5715
Digging Reach On Ground(mm)	5270/5603
Digging Depth(mm)	3085/3440
Vertical Wall Digging Depth(mm)	2503/2713
Cutting Height(mm)	4710/4843
Dumping Height(mm)	3310/3463
Min. Front Swing Radius(mm)	2416/2413
Dozerd-up(mm)	370
Dozer-down(mm)	390
Swing Boom Left Rotation(°)	70°
Swing Boom right Rotation(°)	50°
Emission	3TNV88-BPLY
System maximum flow(L/Min)	92.4
System pressure(Mpa)	24.5
